VOLVO ECR25D

VOLVO ECR25D – SHORT RADIUS COMPACT EXCAVATOR

Increased Capability in Confined Spaces

The Volvo ECR25D short radius excavator offers increased power, stability, and lifting capability while maintaining a reduced tail swing design.

It is ideal for contractors working in urban environments, roadside projects, and sites where space and safety are key considerations.

---

Technical specifications for ECR25D

Here are the key specifications for this product model. Want more details? Download the brochure or contact us.

Engine
Volvo D1.1A

Gross Power
15.6 kW

Net Power
14.8 kW

…at Engine Speed
2,400 rpm

Operating Weight
2,490 – 2,960 kg

Operating Weight, Canopy Version
2,400 – 2,870 kg

Bucket Capacity
0.03 – 0.12 m³

Travel Speed, Low / High
2.4 / 4.5 km/h

Slewing Speed
9.4 rpm

Breakout Force
22.3 kN

Tear Out Force (arm breakout force)
17.3 kN

Overall Width
1,550 mm

Overall Length
3,924 mm

Main Hydraulic Pump Max. Flow
58 l/min

Boom Swing Angle, Left / Right
72 / 56 °

Based on machine configuration: With 300mm shoe.

---

Performance & Productivity

The ECR25D provides strong digging forces and smooth hydraulic response, enabling efficient operation across a range of applications. Its stable platform allows operators to lift and dig confidently while maintaining precise control.

The short radius configuration allows the machine to work safely in narrow spaces without sacrificing productivity.

Operator Environment

The operator station is designed for comfort, ease of use, and excellent visibility. Intuitive controls and a well-laid-out working area allow operators to remain productive throughout the day.

Low noise and vibration levels contribute to a more comfortable working experience.

Built for Durability

Reinforced components and protected systems ensure the ECR25D can withstand harsh site conditions. Volvo’s proven build quality supports long service life and dependable performance.

Efficiency & Ownership

Efficient engine performance and easy servicing help reduce fuel and maintenance costs. These features make the ECR25D a cost-effective solution for owner-operators and fleet managers.

Applications

• Urban construction and maintenance
• Utilities and infrastructure
• Landscaping and site preparation
• Hire and rental operations

Why Choose the ECR25D?

The ECR25D delivers the ideal balance of compact size, increased performance, and reduced tail swing, making it a dependable choice for confined work environments.
