CRAWLER EXCAVATOR – HMK 140 LC

Providing the required power for the job with the advantage of having high performance in different working fields.

The Hidromek HMK 140 LC offers durability, easy usage, operator comfort and safety together with an enjoyable working environment.

Maximum Power 106,7 HP (78,5 kW) @2000 rpm

Bucket Digging Force (ISO) 10,000 kgf

Bucket Capacity 0.6 m³

Operating Weight 14,900 kg

Need a Price or Availability?
Simply request a price or speak to our team, we’ll respond within 1 working hour.

📞 01634 867 777
📧 enquiries@langhamcontracting.co.uk

Request a Price

HIDROMEK – HMK 140 LC

More Durable
Produced to have reinforced heavy duty construction considering maximum performance, long life and smooth operation in severe field conditions, HİDROMEK excavators ensure more durability with the improvements made in the new H4 Series. With their reinforced heavy duty construction produced at HİDROMEK’s modern production facilities and going through sensitive quality-control processes, H4 Series excavators have excellent durability.

Safe working environment

ROPS & FOPS Cabin
Having the standards of ROPS (Roll Over Protective Structure) & FOPS (Falling Object Protective Structure), H4 Series excavators provide maximum safety and durability.

Wide Vision Capacity
Designed with giving special importance to occupational safety, H4 Series ensure excellent vision by minimising the blind spot on the side and rear cameras. Along with the increase in the number of led headlights, the night vision is significantly improved on H4 Series excavators; in addition, there are also red handles and warning labels providing maximum safety for the operator.

Audio Warning Systems
H4 Series excavators enable safer working environment with their automatic starting horn, swing warning system and travel warning system.

OPERATING WEIGHT
Operating Weight
14,900 kg

ENGINE
Maximum Power
106,7 HP (78,5 kW) @2000 rpm

Maximum Torque
375 Nm @1800 rpm

Brand – Model
ISUZU 4JJ1X

Type
Water cooled, 4 cycle, 4 cylinders, line type direct injection, turbocharger, intercooler, electronic diesel engine

Number of cylinders
4

Bore x Stroke
95.4 mm x 104.9 mm

Displacement
2999cc

HYDRAULIC SYSTEM
Pump Type
Double variable displacement axial piston pumps

Maximum Flow
2 x 129 L/min

Pilot Pump
20 L/min

Attachment
350 kgf/cm²

Power Boost
372 kgf/cm²

Travel
350 kgf/cm²

Swing
300 kgf/cm²

Pilot
40 kgf/cm²

SWING SYSTEM
Swing Speed
11.1 rpm

TRAVEL
Maximum Drawbar Pull
11,600 kgf

High Speed
5.60 km/h

Low Speed
3.30 km/h

DIGGING PERFORMANCE
Bucket Digging Force (ISO)
10,000 kgf

Bucket capacity
0.6 m³

Arm Breakout Force (ISO)
7,300 kgf

WORKING DIMENSIONS
Boom Dimension
4.600 mm

Arm Dimension
2300mm

Maximum Digging Depth
5360mm

Maximum Reach at Ground Level
8070mm

If you’d like to know more information about the Hidromek HMK140 LC, or need help choosing the right specification for your project, please get in touch with our team. We’re here to provide expert advice, availability, and pricing, and can help you find the best solution for your requirements quickly and efficiently.
