CRAWLER EXCAVATOR – HMK 410 LC UHD

Being produced with developed hydraulic system design, HİDROMEK’s new H4 Series excavators offer an outstanding performance by working faster, more productively and more efficiently.

H4 Series excavators produce more work with less fuel; hence, they are more profitable for their users than ever.

Maximum Power 281 HP (210kW)@1900 rpm

Bucket Digging Force (ISO) 25,300 kgf

Bucket Capacity 2.5 m³

Operating Weight 42,200 kg

Need a Price or Availability?
Simply request a price or speak to our team, we’ll respond within 1 working hour.

📞 01634 867 777
📧 enquiries@langhamcontracting.co.uk

Request a Price

HIDROMEK – HMK 410 LC UHD

More Durable
Produced to have reinforced heavy duty construction considering maximum performance, long life and smooth operation in severe field conditions, HİDROMEK excavators ensure more durability with the improvements made in the new H4 Series. With their reinforced heavy duty construction produced at HİDROMEK’s modern production facilities and going through sensitive quality-control processes, H4 Series excavators have excellent durability.

Wide Vision Capacity
Designed with giving special importance to occupational safety, H4 Series ensure excellent vision by minimising the blind spot on the side and rear cameras. Along with the increase in the number of led headlights, the night vision is significantly improved on H4 Series excavators; in addition, there are also red handles and warning labels providing maximum safety for the operator.

Audio Warning Systems
H4 Series excavators enable safer working environment with their automatic starting horn, swing warning system and travel warning system.

OPERATING WEIGHT

Operating Weight
42,200 kg

ENGINE

Maximum Power
281 HP (210kW)@1900 rpm

Maximum Torque
1140 Nm @1500 rpm

Brand – Model
ISUZU 6HK1X

Type
Water-cooled, 4 cycle, 6 cylinders, line type direct injection, turbocharger, intercooler, electronic diesel engine

Number of cylinders
6

Bore x Stroke
115 x 125 mm

Displacement
7790 cc

Emission Class
EU: Stage V

HYDRAULIC SYSTEM

Pump Type
Double variable displacement axial piston pumps

Maximum Flow
2 x 300 L/min

Pilot Pump
28 L/min

Attachment
350 kgf/cm²

Power Boost
380 kgf/cm²

Travel
350 kgf/cm²

Swing
285 kgf/cm²

Pilot
40 kgf/cm²

SWING SYSTEM

Swing Speed
9.2 rpm

TRAVEL

Maximum Drawbar Pull
30,260 kgf

High Speed
5.0 km/h

Low Speed
3.0 km/h

DIGGING PERFORMANCE

Bucket Digging Force (ISO)
25,300 kgf

Bucket capacity
2.5 m³

Arm Breakout Force (ISO)
22,100 kgf

WORKING DIMENSIONS

Boom Dimension
6100 mm

Arm Dimension
2600 mm

Maximum Digging Depth
6530 mm

Maximum Reach at Ground Level
10210 mm

If you’d like to know more information about the Hidromek HMK 410 LC UHD, or need help choosing the right specification for your project, please get in touch with our team. We’re here to provide expert advice, availability, and pricing, and can help you find the best solution for your requirements quickly and efficiently.
